OPERATOR’S MANUAL
Auto Section Control System
11001-1561B-201207
SYSTEM OPERATION / 39
ENABLE AUTO SECTION CONTROL
To enable Auto Section Control:
1. Once a task is selected, press the Open Task button.
2. At the Auto Section Control Main Menu screen enable the following
system functions:
– Lower implement into the ground
– Turn master switch on
– Verify all clutch section switches are on
IMPORTANT: Vehicle speed must be greater than the shutoff speed
set at the IntelliAg Speed Setup screen.
3. Begin driving at desired planting speed.
4. Auto swath lines will appear on the Auto Section Control screen to the
path being driven.
Figure 39
Auto Section Control
DISABLE AUTO SECTION CONTROL
Auto Section Control is disabled by performing any of the following
functions:
• Lifting the implement
• Master switch is turned off
• Manual override of the system (Manual button)
• Vehicle speed is lower than the shutoff speed set at the IntelliAg Speed
Setup screen
• Master section switch is turned off on the row control module
• A lost GPS signal
Auto
Auto
Section
Control
Status
Swath
