OPERATOR’S MANUAL
Auto Section Control System
11001-1561B-201207
38 / SYSTEM OPERATION
8. Current Task
Active task running
9. GPS signal
GPS signal strength
10. Satellites
Number of active satellites
11. System status bar
Provides current status of Auto Section Control
12. Right Section Indicator buttons define all sections in the right group to
be controlled by the right Auto/On/Off button when moved. The color of
the left and right indicator identifies the action (on or off) to occur when
section indicators are moved.
Figure 38
System Status Bar
System Status Cause Resolution
Controller Offline WSMT (PDC) not found Error 100 (See Troubleshooting section)
No Controller WSMT (PDC) not talking or incompatible version Error 100 (Contact dealer to update WSMT (PDC)
software.
System Fault System has encountered a nonrecoverable error 1. Power cycle the system.
2. Disconnect connector on the Auto Section Control
display and reconnect.
3. Create new field or clear current task.
No GPS No data from the GPS Receiver Error 102 (See Troubleshooting section)
Controller Setup WSMT (PDC) is on a Setup screen 1. Finish setup changes on WSMT (PDC) and return to
Main Work screen.
2. Wait for WSMT (PDC) to finish power up process.
Controller Update Need to get data from WSMT (PDC) Error 200 (See Troubleshooting section)
Controller Sync Obtaining data from WSMT (PDC) Wait. System busy.
No Outputs No outputs configured on the WSMT (PDC) Outputs not assigned or assigned incorrectly. Check
IntelliAg Module Configuration screens.
Poor GPS Quality or number of satellites is not at acceptable levels Error 102 (See Troubleshooting section)
Init Loading coverage file Wait. System busy.
Pause WSMT (PDC) is not running WSMT (PDC) system is not active.
Ready WSMT (PDC) is running
Coverage Override Pause Coverage override is on with the implement up
Coverage Override Active Coverage override is on with the implement down
