Great Plains DICKEY-john Auto Section Control - Manual (Page 38)

OPERATOR’S MANUAL
Auto Section Control System
11001-1561B-201207
36 / FIELD PREPARATION
OVERWRITE FIELD BOUNDARY
An Overwrite Field Boundary screen appears if the Auto Section Control
terminal already has the existing boundary with the same file name
associated with a field.
– Press the OK button to overwrite the existing boundary.
– Press the Cancel button to retain the existing boundary.
Figure 35
Overwrite Field Boundary
AUTO SECTION CONTROL STATUS
The Auto Section Control terminal will be in ready mode at the Select Task
screen. Auto Section Control status will indicate No Field Selected until a
task is opened and the system is enabled once GPS has been acquired.
Figure 36
Auto Section Control Terminal
