Great Plains Manufacturing, Inc. Table of Contents Index Appendix A - Reference Information 163
2013-04-24 Table of Contents Index 401-627M
Connections, 16-Port Air Box, Right, 2 of 3
Facing forward/right, with planter folded.
31-Row: YP4025A-3115
32-Row: YP4025A-3215E, YP4025A-32TR, YP4025A-32TR70
Section Right Center Right Wing
Air Box P09 P10 P11 P12 P13 P14 P15 P16
Ctr Guide - - - C5 C4 C3 C2 C1
Wing Guide - - - W5 W4 W3 W2 W1
Rack Tube T8 T7 T6 T5 T4 T3 T2 T1
Y-Tube
Y Y Y Y Y Y Y Y
Row Unit cap 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Section Left Wing Left Center
Air Box P09 P10 P11 P12 P13 P14 P15 P16
Ctr Guide - - - C5 C4 C3 C2 C1
Wing Guide - - - W5 W4 W3 W2 W1
Rack Tube T8 T7 T6 T5 T4 T3 T2 T1
Y-Tube
Y Y Y Y Y Y Y Y
Row Unit 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
