160 YP4025A Table of Contents Index Great Plains Manufacturing, Inc.
401-627M Table of Contents Index 2013-04-24
Connections, 16-Port Air Box, Left, 1 of 3
Facing forward/left, with planter folded.
16 Row: YP4025A-1670, YP4025A-1630
24 Row: YP4025A-2420
Section Left Wing Left Center
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 C4 C5 - - -
Wing Guide W1 W2 W3 W4 W5 - - -
Rack Tube T1 T2 T3 T4 T5 T6 T7 T8
Row Unit R01 R02 R03 R04 R05 R06 R07 R08
Section Left Wing Left Center
Air Box P01 P02 P03 P04 P05 P06 P07 P08
Ctr Guide C1 C2 C3 C4 C5 - - -
Wing Guide W1 W2 W3 W4 W5 - - -
Rack Tube T1 T2 T3 T4 T5 T6 T7 T8
Y-Tube
Y | Y | Y | Y |
Row Unit 1 2 3 4 5 6 7 8 9 10 11 12
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
