Great Plains Manufacturing, Inc. Table of Contents Index Appendix A - Reference Information 161
2013-04-24 Table of Contents Index 401-627M
Connections, 16-Port Air Box, Right, 1 of 3
Facing forward/right, with planter folded.
16-Row: YP4025-1670, YP4025A-1630
24-Row: YP4025A-2420
Section Right Center Right Wing
Air Box P09 P10 P11 P12 P13 P14 P15 P16
Ctr Guide - - - C5 C4 C3 C2 C1
Wing Guide - - - W5 W4 W3 W2 W1
Rack Tube T8 T7 T6 T5 T4 T3 T2 T1
Row Unit 9 10 11 12 13 14 15 16
Section Right Center Right Wing
Air Box P09 P10 P11 P12 P13 P14 P15 P16
Ctr Guide - - - C5 C4 C3 C2 C1
Wing Guide - - - W5 W4 W3 W2 W1
Rack Tube T8 T7 T6 T5 T4 T3 T2 T1
Y-Tube
| Y | Y | Y | Y
Row Unit 13 14 15 16 17 18 19 20 21 22 23 24
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
1
P01 P16
GUIDES
RACK
AIR BOX
RACK
29298
1 1
2 2
3
4
5
3
4
5
2 3 4
5
T6 T7 T8
C W
T
S
Y
T
