Great Plains YP4025A Operator Manual User Manual
Operator manual, Manufacturing, inc

Manufacturing, Inc.
© Copyright 2013
Printed 2013-04-24
401-627M
EN
ORIGINAL INSTRUCTIONS
Operator Manual
YP4025A
40 Foot 3-Section Yield-Pro
®
Planter
with Air-Pro
®
Seed Meters
Read the operator manual entirely. When you see this symbol, the
subsequent instructions and warnings are serious - follow without
exception. Your life and the lives of others depend on it!
Illustrations may show optional equipment not supplied with standard unit or may
depict similar models where a topic is identical.
29817
