Using This Manual
This manual will familiarize you with planning, unloading,
assembly, and some calibration of the planter. Most
operating information is contained in the Operator
manual (401-647M). It is essential that the Operator
manual be available during assembly and checkout.
The information in this manual is current at printing.
Some parts may change to assure top performance.
Definitions
The following terms are used throughout this manual.
A crucial point of information related to the preceding topic.
Read and follow the directions to remain safe, avoid serious
damage to equipment and ensure desired field results.
Note: Useful information related to the preceding topic.
What’s On The Truck
Refer to Figure 2
The 3PYPA planter is delivered from the factory on a
flatbed semi-trailer. It needs to be unloaded from the
truck at the spot where final assembly takes place.
It is expected that final delivery to the customer will be
done using the planter’s own transport wheels, after final
assembly.
Right-hand and left-hand as used in
this manual are determined by facing
the direction the machine will travel
while in use unless otherwise stated.
An orientation rose in some line art
illustrations shows the directions of:
Up, Back, Left, Down, Front, Right.
Document Family
401-647M Owner’s Manual (this document)
401-647B Seed Rate Charts
401-647P Parts
401-647Q Pre-Delivery manual
DICKEY-john
®
IntelliAg
®
manuals:
110011508 Planter/Drill Control, User Level 1
110011501 Planter/Drill Control, User Level 2&3
110011531 3PYPA-1236 Quick-Start Guide
110011531 3PYPA-1238 Quick-Start Guide
110011531 3PYPA-1240 Quick-Start Guide
110011530 3PYPA-1630 Quick-Start Guide
110011528 3PYPA-24TR36 Quick-Start Guide
110011528 3PYPA-24TR38 Quick-Start Guide
110011528 3PYPA-24TR40 Quick-Start Guide
110011529 3PYPA-3115 Quick-Start Guide
110011529 3PYPA-32TR30 Quick-Start Guide
110011126 DICKEY-john
®
hopper level sensor install
U
D
F
B
L
R
Figure 2
Planter Arriving on Truck
