Page 82
500-642M
01/12/2012
78
TSF1060 and TSF1260
Great Plains Manufacturing, Inc.
Appendix
Specifications and Capacities
TSF-1060-2530
TSF-1060-3620
TSF-1260-2530
TSF-1260-3620
Boom Width
60 feet
18.3m
60 feet
18.3m
60 feet
18.3m
60 feet
18.3m
Nozzle Spacing
30in (76cm)
20in (51cm)
30in (76cm)
20in (51cm)
Nozzle Count
25
36
25
36
Main Tank Capacity
1000 gallons (3785 liters)
1250 gallons (4732 liters)
Flush Tank Capacity
100 gallons (379 liters)
Hand Wash Tank Cap.
5 gallons (18.9 liters)
Marker Foam Tank Cap.
25 gallons (95 liters)
Tractor Requirement
75 hp (55 kW)
100 hp (75 kW)
Closed Center
a
Hydraulic Circuits
a. An optional kit (833-427C) is available for open center tractors. See page 74.
One hydraulic remote (with PTO pump)
Two hydraulic remotes (with hydraulic pump)
b
b. If tractor cannot restrict flow to 6 gpm, purchase a flow-control kit from your Great Plains dealer.
Empty Weight
7520 lbs (3411 kg)
8070 lbs (3660 kg)
Full Weight
16450 lbs (7462 kg)
19075 lbs (8652 kg)
Working Width
63 ft (19.2m)
Transport Width
12 ft (3.7m)
Transport Height
13 ft (4.0m)
Length
22 ft 5in (6.8m)
Clearance
c
c. Lowest part of hitched sprayer is the tractor side of the hitch.
28 in (71cm)
Wheel Spacing
North American models: 80 to 120 inches (203 to 305cm)
Export models: 203 to 290cm (80 to 114in)
Tire Size
320/85R38 Radial
d
d. May be upgraded by Option to 14.9 R46.
14.9 R46 10 Ply
Pumps
e
e. Standard sprayer does not include a pump.
Ace Hydraulic,
Ace Tractor mounted high volume PTO pump - 540 RPM,
Ace Tractor mounted high volume PTO pump - 1000 RPM 1
3
⁄
8
in spline, or
customer-provisioned 90 gpm at 30 psi (341 liters/min at 207 kPa)
Tire Inflation Chart
Tire Warranty Information
Wheel
Tire Size
Inflation
All tires are warranted by the original manufacturer of the tire.
Tire warranty information is found in the brochures included
with your Operator’s and Parts Manuals or online at the man-
ufacturer’s websites listed below. For assistance or informa-
tion, contact your nearest Authorized Farm Tire Retailer.
Manufacturer
Website
Firestone
Gleason
Titan
Transport
13.6-38 6 Ply Tubeless
22 psi
152 kPa
Transport
14.9 R46 4* 10 Ply
Radial
36psi
221 kPa
Transport
320/85R38 Radial
52 psi
359 kPa
