01/12/2012

500-642M

Great Plains Manufacturing, Inc.

Adjustments

55

Adjustments

The following table summarizes the available adjust-
ments. Not all are in this section of the manual.

General Field Adjustments

Boom Height

After calibrating the sprayer for the specific nozzle that
will be used at a desired pressure and tractor speed, the
main field adjustment is the boom height. See “Boom
Height
” on page 55.
Depending on which type of nozzle
is being used, set the boom height so that the correct
overlap for that specific nozzle is achieved. If the crop
canopy is taller in some fields than others adjust the
boom height accordingly. Refer to the Nozzle Charts in
the Application Guide located in this manual to deter-
mine the height of the boom needed.

EXAMPLE:
A 2.5 Metercone nozzle at 20 inch spacing is being used.
From the Nozzle Chart (refer to the Application Guide),
a height of 19 to 21 inches above the top of the crop is
required. If the crop is 6 inches off the ground, the boom
height should be set to 25 to 27 inches off the ground.

Nozzle Pressure

Another area that will need some field adjustments is the
nozzle pressure. As the tank level decreases the boom
pressure may need to be adjusted to keep the pressure
at the same magnitude for what the sprayer was cali-
brated for if the sprayer is not equipped with a monitor.
Watch the pressure gauge and be aware of changes in
the pressure.

Adjustment

Page

Adjustment Affects

Leveling Sprayer

23

Frame Level Adjustment

24

Proper tank drainage and correct boom height control

Leveling Boom

24

Consistent boom height across all rows

Hydraulic Flow Limiter

26

Pump protection and coarse pumping rate

Spraying Setup

30

Correct material pressure and flow

Manual Throttle Valve

30

Maximum consistency of rate control

Agitation

47

Consistent materials solution

Boom Adjustments

Boom Height

48

Correct spray cone overlap for even application

Elevator Slide

67

Sooth movement and consistent boom level

Break Away Spring

57

Proper boom end response to obstacles

Auto-Boom adjustments

See separate Raven manual

Nozzle Selection

see separate Application Guide and nozzle slide chart

Initial GPM and pressure

see separate Application Guide and nozzle slide chart

Foam setup and rate

see separate manual

Axle Wheel Spacing Adjustment

56

Tire tracks relative to rows and tractor tires
