Great Plains Manufacturing, Inc.

Troubleshooting

59

01/12/2012

500-642M

Pressure
cannot
decrease

Pump or elec-
tric ball valve

Tank agitation restricted

Check that the agitator valve is open and that
the liquid is being agitated

Liquid will
not induct

Chemical
Inductor

Make sure the valve below the
inductor tank is open

Make sure the pump is in opera-
tion and has prime

Make sure the venturi bypass
valve is open

Inductor
overflow

Chemical
Inductor

Close valve below inductor tank
until pump is running, has pres-
sure and venturi valve is open

Problem

Problem

Area

Specific Checks

Solutions

Firing Diagram for Fasse 700-0807-4208 Great Plains 833-423C

Switch No.

Boot Color

Switch Position

Hot Wires

Pin Out Location

Pressure Ports

Tank Ports

Function

Left Foam (stat)

Red & Wht 4 Cond

D-4WP, A-4WP

Left Foam Marker

1 Long

White

Center (off)

---------

---------

---------

---------

Off

Right Foam (stat)

Red & Grn 4 Cond

D-4WP, C-4WP

Right Foam Marker

2 Long

Red

Up (mom)

Red/Blk & Grn

5-12P, 10-12P

C5

Left Tilt Up

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Red/Blk & Grn & Blk/Wht

5-12P, 10-12P, 9-12P

C5

Left Tilt Down

3 Long

White

Up (mom)

Org/Blk & Grn

6-12P, 10-12P

C4

Center Up

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Org/Blk & Grn & Blk/Wht

6-12P, 10-12P, 9-12P

C4

Center Down

4 Long

Blue

Up (mom)

Wht/Blk & Grn

7-12P, 10-12P

C3

Right Tilt Up

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Wht/Blk & Grn & Blk/Wht

7-12P, 10-12P, 9-12P

C3

Right Tilt Down

5 Short

Green

Up (mom)

Grn/Wht & Blu/Wht & Grn

A-3P, B-3P, 10-12P

C7

C14

Left Outer Fold

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Grn/Wht & Blu/Wht & Grn & Blk/Wht

A-3P, B-3P, 10-12P, 9-12P

C14

C7

Left Outer Unfold

6 Short

Yellow

Up (mom)

Grn/Blk & Red/Wht & Grn

12-12P, C-3P, 10-12P

C6

C13

Left Inner Fold

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Grn/Blk & Red/Wht & Grn & Blk/Wht 12-12P, C-3P, 10-12P, 9-12P

C13

C6

Left Inner Unfold

7 Short

Grey

Up (mom)

Wht & Blu & Grn

3-12P, 8-12P, 10-12P

C2

C9

Right Inner Fold

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Wht & Blu & Grn & Blk/Wht

3-12P, 8-12P, 10-12P, 9-12P

C9

C2

Right Inner Unfold

8 Short

Red

Up (mom)

Red & Org & Grn

1-12P, 2-12P, 10-12P

C1

C8

Right Outer Fold

Center (off)

---------

---------

---------

---------

Off

Down (mom)

Red & Org & Grn & Blk/Wht

1-12P, 2-12P, 10-12P, 9-12P

C8

C1

Right Outer Unfold

---------

---------

---------

Blk (zip)

---------

---------

---------

Ground

---------

---------

---------

Blk

11-12P

---------

---------

Ground

---------

---------

---------

Blu/Blk

4-12P

---------

---------

Ground

---------

---------

---------

Blk

B-4WP

---------

---------

Ground

29641
