Dante Controller User Guide
Copyright © 2014 Audinate Pty Ltd. All rights reserved. -50-
n Device Config : rename device, change sample rate and set other attributes (as relevant to device
type)
n Network Config : view and edit network configuration
n Baseboard: only available when the Dante device is mounted on a Dante PDK audio baseboard
(NOTE: the device must be in SPI Master mode)
Device View Menu bar
The menu bar in the Device View contains the following menus:
File
n Close Window
Device
n Refresh: Refreshes the displayed network / device data
n Create Multicast Flow
View
n Show/Hide Channel Groups
Help
n About: Shows Dante Controller version and current log file
n License: Displays the license text
n Contents: Opens a help window and displays help contents
Device View Toolbar
The Device View toolbar contains the following buttons:
Refresh Re-load routing and configuration information for
the current device.
Web Config Some Dante devices can be configured via a web
interface. This button opens a web browser
window which can be used to perform functions
such as firmware upgrades. This feature is not
supported on all Dante devices.
Identify Identify the current device by, for example, causing
its LEDs to flash. Note that this feature is not
supported on all Dante devices.
Multicast Configure multicast transmit flows on the current
device.
Channel
Groups Activates / deactivates Channel Groups .
The toolbar also provides a drop down list of all available devices on the network, which allows you to
switch the Device View to a different device.
