5 Parts Breakdown (Continued)
ITEM PART No. DESCRIPTION REQ’D
1 82-4190 Outside Escutcheon with Cylinder Hole and Key Pad, or Key Pad/Prox (G1-LU, G1-PK, G1-TU, G1-TP) 1
82-4191 Outside Escutcheon without Cylinder Hole and Key Pad or Key Pad/Prox (G1-LU, G1-PK, G1-TU, G1-TP) 1
82-4192 Outside Escutcheon with Cylinder Hole and Prox Only (G1-PA, G1-TA) 1
82-4193 Outside Escutcheon without Cylinder Hole and Prox Only (G1-PA, G1-TA) 1
82-0493 Outside Escutcheon Housing Only without Cylinder Hole 1
82-0495 Outside Escutcheon Housing Only with Cylinder Hole 1
52-2432 Keypad/Proximity Bezel Assembly w/ Harness (LK) 1
52-2706 Proximity Only Bezel Assembly with Harness (G1-PA, G1-TA) 1
52-2704 Key Pad/Proximity Bezel Assembly with Harness (G1-LU, G1-PK, G1-TU, G1-TP) 1
2 82-3837 Inside Escutcheon with Thumb Turn and 100 User Controller (LK) 1
82-3838 Inside Escutcheon without Thumb Turn and 100 User Controller (LK) 1
82-4182 Inside Escutcheon with Thumb Turn and 2000 User Controller (G1-LU) 1
82-4183 Inside Escutcheon without Thumb Turn and 2000 User Controller (G1-LU) 1
82-4184 Inside Escutcheon with Thumb Turn Prox/Key Pad Controller (G1-PA, G1-PK) 1
82-4185 Inside Escutcheon without Thumb Turn Prox/Key Pad Cont. (G1-PA, G1-PK) 1
82-4186 Inside Escutcheon with Thumb Turn & 2000 User Controller with RF Technology (G1-TU) 1
82-4187 Inside Escutcheon Less Thumb Turn & 2000 User Controller with RF Technology (G1-TU) 1
82-4188 Inside Escutcheon with Thumb Turn & Keypad/Prox or Prox Only Controller (G1-TA, G1-TP) 1
82-4189 Inside Escutcheon Less Thumb Turn & Keypad Prox or Prox Only Controller (G1-TA, G1-TP) 1
82-0492 Inside Escutcheon Housing Only without Thumb Turn 1
82-0494 Inside Escutcheon Housing Only with Thumb Turn 1
52-2440 100 (LK) User Key Pad Controller Assembly 1
52-2783 2000 (G1-LU) User Controller Assembly 1
52-2784 2000 User (G1-PA, G1-PK) Controller Assembly 1
52-2786 2000 User Keypad/Prox Controller Assembly w/ RF Technology (G1-TA, G1-TP)
52-2785 2000 User Keypad Controller Assembly w/ RF Technology (G1-TU)
3 52-0170 Battery Cover 1
52-2509 Battery Cover – RF Technology (G1-TU,G1-TP, G1-TA)
4 01-1212 Security Screw 1
5 01-0297 Security Tool 1
7 82-0507 Thumb Turn 1
8 77-0772 Spindle (Thumb Turn) 1
9 01-0844 Washer (Thumb Turn) 1
10 01-0543 Spring Grip Fastener (Thumb Turn) 1
11 77-0168 Through-bolts #8-32 x 1 7/8” Flat Head Screw 2
12 52-0033 Fire Stop Plate 1
13 01-1500 Fire Stop Screws #8 x 1/2” Type “AB” Phillips Pan Head Self Tap 2
14 82-3088 Inside Spindle Adapter & Plate Assembly 1
15 01-1495 Screw #8-32 x 1/2” 2
16 82-0368 Inside Spindle/Outside Spindle 2
17 82-0347 Inside Spring/Outside Spring 2
18 82-0081 Face Plate no Dead Bolt 1
19 82-0084 Face Plate with Dead Bolt 1
20 01-1028 Face Plate Screws Machine 8-32 x 1/4” 2
21 01-2299 Lock Body Screws/Wood Door #12 x 1 1/4” 2
22 01-1019 Lock Body Screws/Metal Door 12-24 x 1/2” 2
23 82-0184 Cap Nut 1
24 01-0079 Washer 2
25 82-3082 Plate Assembly 1
26 81-0723 Post 2
27 01-1472 Lever Handle Screw, A, E & F Lever 1
28 01-1174 Lever Handle Screw, B, J, L, P & W Lever 1
29
Reference Profile Series catalog for available lever handles
30
31 82-3732 Lockbody Assembly (with deadbolt) (8276 & 8277) 1
82-3733 Lockbody Assembly (without deadbolt) (8278 & 8279) 1
32 01-0803 Battery Alkaline (“AA” cell) 6
33 52-0253 Battery Keeper 1
52-0344 Battery Keeper – RF Technology (G1-TU, G1-TP, G1-TA)
