Profile Series v.G1 Mortise Lock

, an A

SSA ABL

Group company

Reproduction in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.

The SARGENT Profile v.G1 Mortise Lock is designed for areas which require stand alone authorized entry. It is a
self-contained microprocessor-controlled keypad with non-volatile memory. The keypad will hold a total of
100(LK)/2000 (G1-LU, G1-PK, G1-PA, G1-TU, G1-TP, G1-TA) different user codes. User codes “01” & “02” are
utilized for Master and Supervisory Codes, respectively.

This product is operated by six (6) “AA” alkaline batteries. SARGENT mortise locks are designed with quality
components to provide high security, performance and durability.

General Description

Specifications

• Latch - Stainless steel

• Deadbolt - Stainless steel

• Guardbolt - Stainless steel, non handed

• Handed - Easily field reversible without

disassembling the lock body

• Case - 12 gauge heavy duty wrought steel

• Outside lever controlled by any combination of

keypad, Proximity or RF Technology

• Inside lever retracts latch and deadbolt

• Locks furnished for 1-3/4" doors. Can be

furnished for other door sizes upon request.
Consult factory

• U.L. Listed (3 hr.)

Features

• Low battery alert–4 chirps after code entry

• External remote “request to enter” connector

• Master, Emergency or Supervisory code will

unlock door when low battery has expired

• Programming done at the keypad (Except

G1-PA & G1-TA) or with a PDA using SofLink
Plus software and a PC

• Entry of three wrong User Codes disables all

codes for ten seconds. Yellow LED on solid

• Last 15 transactions can be output to

portable printer via infrared link (LK Only)

• Last 2000 (Except LK) transactions can be output

to a PC via a PDA and SofLink™ Plus software
