Passport 1000 pg mortise lock – SARGENT Passport 1000 PG Mortise Locks User Manual
Page 5
ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
82-3088
01-1495
DESCRIPTION
Cylinder & Key Assembly
Cylinder Rosette
Mortise Lock body
Turn Lever Assembly
Inside Lever Handle
Parts Breakdown (Continued)
8200 Series Mortise Lock
PART No.
See catalog
13-0140
See catalog
See catalog
See catalog
See catalog
See catalog
82-0368
82-0612
See catalog
82-0347
Cr-fhm1
Cr-fhws
82-0084
01-0028
77-2591 Tab
Compression Spring
Blocking Ring
Outside Lever Assembly
Spindle
Inside Lever/knob Adapter Plate Assembly
8-32 X 5/8 Machine Screw
Non Loosening Wave Washer
Mortise Rose
Spindle Spring
1/4-20 X 1/2 Machine Screw
12 X 1-1/4 Wood Screw
Outside Front, Stamped
8-32 X 1/4 Machine Screw
5
A7807C
Copyright © 2012, Sargent Manufacturing Company
, an ASSA ABLOY Group company
. All rights reser
ved.
Reproductions in whole or in part without express written permission of Sargent Manufacturing Company is prohibited.
10/31/12
