KP Series
Keypad Mortise Lock
Parts Breakdown (Continued)
Item Part # Description Req.
1 01-0803 Battery Alkaline (“C” cell) 4
2 01-1119 #8-32 x 1-1/2 Flat Head Screw 1
3 01-0297 Security Socket Screw Key (1/8) 1
4 01-1157 #8-32 x 1-1/4 Phillips Pan Head Screw 1
5 01-0440 Flat Washer 1
6 81-0467 Inside Lever (L.H.) A” Design 1
81-0468 Inside Lever (R.H.) A” Design 1
81-0490 Inside Lever B” Design 1
81-0470 Inside Lever E” Design 1
81-0471 Inside Lever F” Design 1
81-4648 Inside Lever H” Design 1
81-0447 Inside Lever J” Design 1
81-0489 Inside Lever L” Design 1
81-0513 Inside Lever P” Design 1
81-0445 Inside Lever W” Design 1
7 01-1472 Lever Handle Screw A, E, F & H (Lever) 1
01-1174 Lever Handle Screw B, J, L, P & W (Lever) 1
8 82-0347 Handle Spring 1
9 82-0368 Spindle 1
10 81-0093 LN” Rose 1
11 01-4388 #8 x 1 Phillips Flat Head Screw 1
12 01-1495 #8-32 x 5/8 Machine Screw 2
13 82-3088 Inside Lever Adapter & Plate Assembly 1
14 52-0033 Fire Stop Plate 1
15 01-1500 #8 x 1/2 Pan Head Self Tapping Screw 2
16 52-2340 Outside Escutcheon & Keypad Assembly 1
17 77-0566 Cylinder Rosette (Size 41 Cylinder) 1
13-0596 Cylinder Rosette (Size 42 Cylinder) 1
18 13-0489 Cylinder Ring (Size 41 Cylinder) 1
13-0490 Cylinder Ring (Size 42 Cylinder) 1
19 13-0140 Compression Spring 1
20 OS-8276 x LNA Outside Lever (R.H.) A” Design 1
(L.H.) A” Design “ 1
OS-8276 x LNB Outside Lever B” Design “ 1
OS-8276 x LNE Outside Lever E” Design “ 1
OS-8276 x LNF Outside Lever F” Design “ 1
OS-8276 x LNH Outside Lever H” Design 1
OS-8276 x LNJ Outside Lever J” Design 1
OS-8276 x LNL Outside Lever L” Design 1
OS-8276 x LNP Outside Lever P” Design 1
OS-8276 x LNW Outside Lever W” Design “ 1
OS-8276 x LA Outside Lever (R.H.) A” Design “ 1
(L.H.) A” Design “
OS-8276 x LB Outside Lever B” Design “ 1
OS-8276 x LE Outside Lever E” Design “ 1
OS-8276 x LF Outside Lever F” Design “ 1
OS-8276 x LH Outside Lever H” Design “ 1
OS-8276 x LJ Outside Lever J” Design “ 1
OS-8276 x LL Outside Lever L” Design 1
OS-8276 x LP Outside Lever P” Design “ 1
OS-8276 x LW Outside Lever W” Design 1
21 01-1028 Outside Front #8-32x1/4 FL HD Screw 2
01-2299 Lockbody Screws for Wood #12x1-1/4 FL HD (not shown) 2
01-1019 Lockbody Screws for Metal #12-24x1/2 FL HD (not shown) 2
22 82-0084 Outside Front (KP8276 & KP8277) 1
82-0081 Outside Front (KP8278 & KP8279) 1
23 KP-8276-hand-finish Lockbody Assembly with deadbolt & cylinder 1
KP-8277-hand-finish Lockbody Assembly with deadbolt only (no cylinder)
KP-8278-hand-finish Lockbody Assembly with cylinder only (no deadbolt)
KP-8279-hand-finish Lockbody Assembly without deadbolt & without cylinder
24
25
82-3730 Inside Escutcheon Assembly (Turn Lever-KP8276/KP8777) 1
1
82-3729 Inside Escutcheon Assembly (Hole Plug-KP8278/KP8779)
26 52-4758 Inside Escutcheon Assembly (Turn Lever-KP8276 only*) 1
* PHR-prefix locks will not allow Emergency or Master Code users entry when deadbolt is thrown.
Entry is through key cylinder override only.
