Manual No. 0-5132 3-1 INSTALLATION
ULTRA-CUT 100
SECTION 3: INSTALLATION
3.01 Installation Requirements
Electric Supply
The electrical supply network, the gas and water supply system must meet local safety standards. This
conformity shall be checked by qualified personnel.
Input Power Input Current Suggested Sizes (See Note)
Voltage Freq. 3-Ph 3-Ph Fuse (Amps) Wire (AWG)
(Volts) (Hz) (kVA) (Amps) 3-Ph 3-Ph
208 50/60 23 64 80 #4 1
230 50/60 24 60 75 #4 1
400 50 28 40 50 #6 1
400 (CE) 50 28 40 50 #6 1
460 50/60 26 33 40 #8 1
600 50/60 25 24 30 #8
Ultra-Cut 100 Power Supply
Line Voltages with Suggested Circuit Protection and Wire Sizes
Based on National Electric Code and Canadian Electrical Code
1 Extra Hard Usage Type SO, SOW, SOO, SOOW, ST, STW, STO, STOW, STOO, STOOW
CAUTION
Fuse and wire sizes are for reference only. The installation must conform to national and local codes for the type
and method of wire being used.
Gas Supply
The customer must supply all gases and pressure regulators. Gases must be of high quality. Pressure
regulators must be double-stage and installed as close as possible to the gas console. Contaminated gas
can cause one or more of the following problems:
• Reduced cutting speed
• Poor cut quality
• Poor cutting precision
• Reduced consumables life.
• Oil or grease contamination from compressed or bottled air can cause fires in conjunction with oxygen.
Cooling System Requirements
Coolant must be added to the system on installation. The amount required varies with torch leads length.
Thermal Dynamics recommends the use of its coolants 7-3580 and 7-3581 (for low temperatures).
Cat. Number and Mixture Mixture Protects To
7-3580 'Extra-Cool TM ' 25 / 75 10° F / -12° C
7-3581 'Ultra-Cool TM ' 50 / 50 -27° F / -33° C
7-3582 'Extreme Cool T M ' Concentrate* -76° F / -60° C
Coolant Capabilities
* For mixing with D-I Cool TM 7-3583
