Power Supply Parts List
6-6
Manual No. 0-5132
ULTRA-CUT 100
NOTE 2:
Auto Gas lead sets include Plasma Gas Hose, Shield
Gas Hose, Preflow Gas Hose, Water Shield Hose,
Fiber Optic Cable, Marking Hose, and Control Cable.
Key
Description
Catalog #
G
Assembly, Torch Lead, 10’ / 3.05 m
4-3053
G
Assembly, Torch Lead, 15’ / 4.6 m
4-3009
G
Assembly, Torch Lead, 20’ / 6 m
4-3010
G
Assembly, Torch Lead, 25’ / 7.6 m
4-3011
G
Assembly, Torch Lead, 30’ / 9.1 m
4-3012
G
Assembly, Torch Lead, 35’ / 10.6 m
4-3013
G
Assembly, Torch Lead, 40’ / 12 m
4-3014
G
Assembly, Torch Lead, 50’ / 15.2 m
4-3015
G
Assembly, Torch Lead, 75’ / 23 m
4-3016
G
Assembly, Torch Lead, 100’ / 30.5 m
4-3017
H,L,Q,R,S,T,U
Auto Gas Lead Set, 10’ / 3.05 m (See Note 2)
4-3086
H,L,Q,R,S,T,U
Auto Gas Lead Set, 15’ / 4.5 m (See Note 2)
4-3087
H,L,Q,R,S,T,U
Auto Gas Lead Set, 25’ / 7.6 m (See Note 2)
4-3088
H,L,Q,R,S,T,U
Auto Gas Lead Set, 35’ / 10.6 m (See Note 2)
4-3089
H,L,Q,R,S,T,U
Auto Gas Lead Set, 50’ / 15.2 m (See Note 2)
4-3090
H,L,Q,R,S,T,U
Auto Gas Lead Set, 75’ / 22.9 m (See Note 2)
4-3091
H,L,Q,R,S,T,U
Auto Gas Lead Set, 100’ / 30.5 m (See Note 2)
4-3092
H,L,Q,R,S,T,U
Auto Gas Lead Set, 125' / 38.1 m (See Note 2)
4-3093
H,L,Q,R,S,T,U
Auto Gas Lead Set, 150’ / 45.7 m (See Note 2)
4-3094
H,L,Q,R,S,T,U
Auto Gas Lead Set, 175’ / 53.3 m (See Note 2)
4-3095
H
Plasma Gas Hose 10’ / 3.05 m
9-7103
H
Plasma Gas Hose 15’ / 4.5 m
9-7104
H
Plasma Gas Hose 25’ / 7.6 m
8-0149
H
Plasma Gas Hose 35’ / 10.6 m
9-7270
H
Plasma Gas Hose 50’ / 15.2 m
9-7271
H
Plasma Gas Hose 75’ / 22.9 m
9-7272
H
Plasma Gas Hose 100’ / 30.5 m
9-7273
H
Plasma Gas Hose 125' / 38.1 m
9-7274
H
Plasma Gas Hose 150’ / 45.7 m
9-7275
H
Plasma Gas Hose 175’ / 53.3 m
9-7276
I
Plasma Lead 4’ / 1.22 m (Torch Valve Assembly to Torch)
9-3333
J
Shield Lead 4’/ 1.22 m (Torch Valve Assembly to Torch)
9-3334
