Manual No. 0-5132 2-5 SPECIFICATIONS
ULTRA-CUT 100
2.10 Gas Requirements
The customer will provide all gases and pressure regulators. Gases must be of high quality. Pressure regulators
shall be double stage. The chart includes gases which may not be used in all applications.
Gas Quality Minimum Pressure Flow
O
2
(Oxygen)
99.5% Purity
(Liquid recommended)
120 psi
8.3 bar / 827 kPa
70 scfh (1982 l/h)
N
2
(Nitrogen)
99.5% Purity
(Liquid recommended)
<1000 ppm O
2
, <32
ppm H
2
O)
120 psi
8.3 bar / 827 kPa
200 scfh (5700 l/h)
Compressed
or Bottled Air
Clean, Dry,
Free of Oil (see Note 1)
120 psi
8.3 bar / 827 kPa
244 scfh (6910 l/h)
H35 (Argon-Hydrogen)
H35 = 35% Hydrogen,
65% Argon
99.995% Purity
(gas recommended)
120 psi
8.3 bar / 827 kPa
90 scfh (2550 l/h)
Ar (Argon)
99-995% Purity
(gas recommended)
80 psi
5.5 bar / 550 kPa
21 scfh (600 l/h)
H
2
O (Water) See Note 2 50 psi (3.5 bar) 10 gph (38 lph)
Ultra-Cut 100 Power Supply: Gas Pressures, Flows, and Quality Requirements
Note 2: The tap water source does not need to be deionized, but in water systems with extremely high
mineral content a water softener is recommended. Tap water with high levels of particulate matter must be
filtered.
Note 1: The air source must be adequately filtered to remove all oil or grease. Oil or grease
contamination from compressed or bottled air can cause fires in conjunction with oxygen.
For filtering, a coalescing filter able to filter to 0.01 microns should be placed as close as
possible to the gas inlets on the Gas Control Module.
2.11 Gas Applications
MATERIAL
PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD PREFLOW PLASMA SHIELD
Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
Air Air Air Air Air Air
N
2
N
2
H
2
0 N
2
N
2
H
2
0
85A CUT Air Air Air
N
2
H 35 N
2
N
2
H 35 N
2
N
2
N
2
H
2
0 N
2
N
2
H
2
0
OPERATION
30A CUT
70 A CUT
100 A CUT
50 A CUT O
2
Air
O
2
O
2
Air
Air
Air
GAS TYPE GAS TYPE GAS TYPE
Air O
2
Air
O 2
Air
Ultra-Cut-100 Gas Applications
MILD STEEL STAINLESS STEEL ALUMINUM
