APPENDIX A-14 Manual 0-2818
Application Electrode Gas Distributor Tip Shield Cup
Drag Cutting 9-8407 8-7501 8-7503 8-7500
Cutting (without Standoff Cup) 9-8407 8-7501 9-7726 (60A) or 9-7728 (80A) 8-7500
Cutting (with Standoff Cup) 9-8407 8-7501 9-7726 (60A) or 9-7728 (80A) 8-7507
Gouging 9-8407 8-7508 8-7506 8-7500
Consumable Matrix For Pak Master 100XL Plus
APPENDIX 8: PAK MASTER 100XL PLUS SYSTEM DATA
NOTE
For CE Applications refer to Appendix 10.
Cut Quality on Various Materials and Thicknesses
The following table defines the cut quality on various
materials and thicknesses:
Cut Quality on Various Materials
Material Type of Type of Cut
Thickness Material Gas Characteristics
Carbon Steel Air Good - Excellent
Stainless Air Good - Excellent
Aluminum Air Good - Excellent
Gage
to
one inch
Description of Cut Characteristics:
Excellent - Minimum bevel (0 - 4°), minimum kerf (2 x tip
orifice diameter), little or no dross, smooth cut
surface.
Good - Slight bevel (0 - 10°), slightly wider kerf (2-1/2 x tip
orifice diameter), some dross (easily removed), me-
dium-smooth cut surface, slight top edge rounding.
Cutting Range
Material Most Metals
Up to 1 inch (25.4 mm)
Speed 6 ipm (0.15 mpm)
Pierce Rating
Material Carbon Steel
Distance 3/8 inch (9.5 mm)
Transfer Distance 3/8 inch (9.5 mm)
Gouging
Width 1/4 inch (6.3 mm)
Depth 3/16 inch (4.76 mm)
Number Passes Single
Speed 20 ipm (0.5 mpm)
Bevel Cut Capability
Degrees 0° to 45°
Material Thickness 1/2 inch (13 mm)
Gas Requirement
Type Gas Air
Operating Pressure 70 psi (4.8 bar)
Max Input Pressure 125 psi (8.6 bar)
Cutting & Gouging
Total Flow
400 scfh (190 lpm)
Torch Specifications For
CE Pak Master 100XL Plus Power Supply
