APPENDIX
A-8
Manual 0-2818
Application
Electrode
Gas Distributor
Tip
Shield Cup
Drag Cutting
9-8402
8-7501
8-7503
8-7500
Cutting (without Standoff Cup)
9-8402
8-7501
9-7726
8-7500
Cutting (with Standoff Cup)
9-8402
8-7501
9-7726
8-7507
Gouging
9-8402
8-7508
8-7506
8-7500
Consumable Matrix For CutMaster 80XL
APPENDIX 5: CUTMASTER 80XL SYSTEM DATA
Cut Quality on Various Materials and
Thicknesses
The following table defines the cut quality on various
materials and thicknesses:
Cut Quality on Various Materials
Material
Type of
Type of
Cut
Thickness
Material
Gas
Characteristics
Carbon Steel
Air
Good - Excellent
Stainless
Air
Good - Excellent
Aluminum
Air
Good - Excellent
Gage
to
3/4 inch
Description of Cut Characteristics:
Excellent -
Minimum bevel (0 - 4°), minimum kerf (2 x tip
orifice diameter), little or no dross, smooth cut
surface.
Good -
Slight bevel (0 - 10°), slightly wider kerf (2-1/2 x tip
orifice diameter), some dross (easily removed), me-
dium-smooth cut surface, slight top edge rounding.
Cutting Range
Material
Most Metals
Up to
7/8 inch (22.2 mm)
Speed
10 ipm (0.25 mpm)
Pierce Rating
Material
Carbon Steel
Thickness
3/8 inch (9.5 mm)
Transfer Distance
3/8 inch (9.5 mm)
Gouging
Width
3/16 inch (4.76 mm)
Depth
1/8 inch (3.18 mm)
Number Passes
Single
Speed
20 ipm (0.5 mpm)
Bevel Cut Capability
Degrees
0° to 45°
Material Thickness
1/2 inch (13 mm)
Gas Requirement
Type Gas
Air
Operating Pressure
60 psi (4.1 bar)
Max Input Pressure
125 psi (8.6 bar)
Cutting & Gouging
Total Flow
310 scfh (146 lpm)
Torch Specifications For
CutMaster 80XL Power Supply
