07 torch parts selection – Tweco 151 with SL100SV User Manual
Page 33
Manual 0-4691
3-9
INSTALLATION
3
3.07 Torch Parts Selection
1.
Check the torch for proper consumable parts. The parts supplied in the torch may not be correct for the operator's chosen
amperage level. The torch parts must correspond with the type of operation.
Art # A-04173
Electrode
Start Cartridge
Tip
Ohmic Clip
(If Installed)
Torch Head
Shield Cup Body
Shield Cap
Deflector
