PARTS LISTS

6-6

Manual 0-4691

6.08 Power Supply Left Side Internal Replacement Parts

Item #

Qty

Description

Ref #

Catalog #

Fuse

for 208/230-Volt Power Supplies

9-8588

for 400-Volt & 415-Volt Power Supplies

9-8602

for 460-Volt Power Supplies

9-8583

for 600-Volt Power Supplies

9-8638

Main Input Contactor

for 208/230-Volt Power Supplies

9-8587

for 400-Volt, 415-Volt, 460-Volt and 600-Volt Power Supplies

9-8554

Connector PCB

9-8576

for (RoHS)

9-0051

PC Board Assembly, Logic

9-8338

for (RoHS)

9-0071

PC Board Assembly Kit, IGBT Circuit (for 208/230V, 400V,

9-8334

415-Volt and 460V units)
for (RoHS)

9-0053

PC Board Assembly Kit, IGBT Circuit (for 600V units)

9-8666

IGBT Diode

IGBT PCB

Thermal Pad

Input Diode Kit

9-8030

PC Board Assembly, Main Power

for 208/230-Volt Power Supplies

9-8340

for 400-Volt Power Supplies

9-8342

for 415-Volt Power Supplies

9-8670

for 460-Volt Power Supplies

9-8341

for 600-Volt Power Supplies

9-8343

EMI Filter Kit (CE Power Supplies only)

9-8664
