APPENDIX A-12 Manual 0-4691
A
APPENDIX 12: INTERFACE PCB SWITCH SETTINGS
(Division Factors 36-43)
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8 Divide Factor
1 0 1 0 1 0 1 1 36.03
0 1 1 1 1 0 0 0 36.16
1 0 1 0 1 1 0 0 36.18
0 1 1 1 1 0 0 1 36.31
1 0 1 0 1 1 0 1 36.32
0 1 1 1 1 0 1 0 36.44
1 0 1 0 1 1 1 0 36.46
0 1 1 1 1 0 1 1 36.59
1 0 1 0 1 1 1 1 36.61
0 1 1 1 1 1 0 0 36.74
0 1 1 1 1 1 0 1 36.88
1 0 1 1 0 0 0 0 36.97
0 1 1 1 1 1 1 0 37.02
1 0 1 1 0 0 0 1 37.11
0 1 1 1 1 1 1 1 37.16
1 0 1 1 0 0 1 0 37.25
1 0 1 1 0 0 1 1 37.39
1 0 1 1 0 1 0 0 37.55
1 0 1 1 0 1 0 1 37.69
1 0 1 1 0 1 1 0 37.83
1 0 1 1 0 1 1 1 37.97
1 0 1 1 1 0 0 0 38.15
1 0 1 1 1 0 0 1 38.30
1 0 1 1 1 0 1 0 38.44
1 0 1 1 1 0 1 1 38.58
1 0 1 1 1 1 0 0 38.73
1 0 1 1 1 1 0 1 38.87
1 0 1 1 1 1 1 0 39.01
1 0 1 1 1 1 1 1 39.16
1 1 0 0 0 0 0 0 40.07
1 1 0 0 0 0 0 1 40.21
1 1 0 0 0 0 1 0 40.35
1 1 0 0 0 0 1 1 40.49
1 1 0 0 0 1 0 0 40.64
1 1 0 0 0 1 0 1 40.79
1 1 0 0 0 1 1 0 40.93
1 1 0 0 0 1 1 1 41.07
1 1 0 0 1 0 0 0 41.25
1 1 0 0 1 0 0 1 41.40
1 1 0 0 1 0 1 0 41.53
1 1 0 0 1 0 1 1 41.68
1 1 0 0 1 1 0 0 41.83
1 1 0 0 1 1 0 1 41.97
1 1 0 0 1 1 1 0 42.11
1 1 0 0 1 1 1 1 42.25
1 1 0 1 0 0 0 0 42.62
1 1 0 1 0 0 0 1 42.76
1 1 0 1 0 0 1 0 42.90
Automation Interface Switch Setting Chart, Division Factors 36-43
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
