APPENDIX 10: INTERFACE PCB SWITCH SETTINGS
(Division Factors 30-33)
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8 Divide Factor
0 1 0 1 0 0 0 1 30.01
1 0 0 0 0 1 0 1 30.03
0 1 0 1 0 0 1 0 30.15
1 0 0 0 0 1 1 0 30.17
0 1 0 1 0 0 1 1 30.29
1 0 0 0 0 1 1 1 30.31
0 1 0 1 0 1 0 0 30.44
1 0 0 0 1 0 0 0 30.49
0 1 0 1 0 1 0 1 30.59
1 0 0 0 1 0 0 1 30.64
0 1 0 1 0 1 1 0 30.73
1 0 0 0 1 0 1 0 30.78
0 1 0 1 0 1 1 1 30.87
1 0 0 0 1 0 1 1 30.92
0 1 0 1 1 0 0 0 31.05
1 0 0 0 1 1 0 0 31.07
0 1 0 1 1 0 0 1 31.20
1 0 0 0 1 1 0 1 31.21
0 1 0 1 1 0 1 0 31.33
1 0 0 0 1 1 1 0 31.35
0 1 0 1 1 0 1 1 31.48
1 0 0 0 1 1 1 1 31.50
0 1 0 1 1 1 0 0 31.63
0 1 0 1 1 1 0 1 31.77
1 0 0 1 0 0 0 0 31.86
0 1 0 1 1 1 1 0 31.91
1 0 0 1 0 0 0 1 32.00
0 1 0 1 1 1 1 1 32.05
1 0 0 1 0 0 1 0 32.14
1 0 0 1 0 0 1 1 32.28
0 1 1 0 0 0 0 0 32.43
1 0 0 1 0 1 0 0 32.44
0 1 1 0 0 0 0 1 32.57
1 0 0 1 0 1 0 1 32.58
0 1 1 0 0 0 1 0 32.71
1 0 0 1 0 1 1 0 32.72
0 1 1 0 0 0 1 1 32.85
1 0 0 1 0 1 1 1 32.86
Automation Interface Switch Setting Chart, Division Factors 30-33
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
