PARTS LISTS

6-8

Manual 0-4691

6

6.09 Right Side Internal Replacement Parts

Item #

Qty

Description

Ref #.

Catalog #

1

1

Assembly, Pressure Switch/Solenoid

Sol1, Ps1

9-8329

2

1

Assembly, Pilot Board

9-8337

for (RoHS)

9-0070

3

1

Fan, 220V, 115 CFM

9-7687

4

1

Assembly, Main Transformer

T5

for 208/230-Volt units

9-8345

for 400-Volt & 415-Volt units

9-8347

for 460-Volt units

9-8346

for 600-Volt units

9-8348

5

1

Assembly, Output Inductor

L1

9-8591

6

1

Assembly, Output Power PCB

9-8339

for (RoHS)

9-0078

7

Assembly, Output Diode PC Board Kit

9-8349

1

Output Diode Assembly

1

Thermal Pad
for (RoHS)

9-0050

8

1

Automation Interface PC Board

9-4894

9

1

Automation Interface Wire Harness

9-4895

10

1

Transformer (only in power supplies connected to SL100SV Torch

9-9449

(with solenoid on mounting tube)
