PARTS LISTS 6-14 Manual 0-4691
6
6.12 Torch Consumables
The illustration shows all consumable parts for the SL100 torch.
The Shield Cup Body with the Deflector Shield Cap provides extended parts life and improved resistance to reflected
heat.
The electrode and start cartridge are the same for all operations.
6.13 Torch Spare Parts Kits
Item
Catalog No.
40-Amp Kit,
Cat No. 5-0054
60-Amp Kit,
Cat No. 5-0079
80-Amp Kit,
Cat No. 5-0122
100-Amp Kit,
Cat No. 5-0174
Electrode 9-8215 3 3 3 3
30A Standoff Tip 9-8206 5 5 5 5
40A Standoff Tip 9-8208 5 5 5 5
60A Standoff Tip 9-8210 5 5 5
80A Standoff Tip 9-8211 5 5
100A Standoff Tip 9-8212 5
Shield Cup Body 9-8237 1 1 1 1
Shield Cap, Deflector 9-8243 1 1 1 1
Shield Cap, Machine, 40A 9-8245 1 1 1 1
Shield Cap, Machine, 60A 9-8238 1 1 1
Shield Cap, Machine, 70-100A 9-8239 1 1
Large O-Ring 8-3487 1 1 1 1
Small O-Ring 8-3486 1 1 1 1
Start Cartridge 9-8213 1 1 1 1
Ohmic Clip Kit 9-8224 1 1 1 1
Automation Torch Spare Parts Kit Contents
