APPENDIX A-8 Manual 0-4691
A
Switch 1 Switch 2 Switch 3 Switch 4 Switch 5 Switch 6 Switch 7 Switch 8 Divide Factor
0 0 0 0 0 0 0 0 16.56
0 0 0 0 0 0 0 1 16.70
0 0 0 0 0 0 1 0 16.84
0 0 0 0 0 0 1 1 16.98
0 0 0 0 0 1 0 0 17.14
0 0 0 0 0 1 0 1 17.28
0 0 0 0 0 1 1 0 17.42
0 0 0 0 0 1 1 1 17.56
0 0 0 0 1 0 0 0 17.74
0 0 0 0 1 0 0 1 17.89
0 0 0 0 1 0 1 0 18.03
0 0 0 0 1 0 1 1 18.17
0 0 0 0 1 1 0 0 18.32
0 0 0 0 1 1 0 1 18.46
0 0 0 0 1 1 1 0 18.60
0 0 0 0 1 1 1 1 18.75
0 0 0 1 0 0 0 0 19.11
0 0 0 1 0 0 0 1 19.25
0 0 0 1 0 0 1 0 19.39
0 0 0 1 0 0 1 1 19.53
0 0 0 1 0 1 0 0 19.69
0 0 0 1 0 1 0 1 19.83
0 0 0 1 0 1 1 0 19.97
0 0 0 1 0 1 1 1 20.11
0 0 0 1 1 0 0 0 20.29
0 0 0 1 1 0 0 1 20.44
0 0 0 1 1 0 1 0 20.58
0 0 0 1 1 0 1 1 20.72
0 0 0 1 1 1 0 0 20.87
0 0 0 1 1 1 0 1 21.01
0 0 0 1 1 1 1 0 21.15
0 0 0 1 1 1 1 1 21.30
0 0 1 0 0 0 0 0 21.67
0 0 1 0 0 0 0 1 21.81
0 0 1 0 0 0 1 0 21.95
0 0 1 0 0 0 1 1 22.09
0 0 1 0 0 1 0 0 22.25
0 0 1 0 0 1 0 1 22.39
0 0 1 0 0 1 1 0 22.53
0 0 1 0 0 1 1 1 22.67
0 0 1 0 1 0 0 0 22.85
0 0 1 0 1 0 0 1 23.00
0 0 1 0 1 0 1 0 23.14
0 0 1 0 1 0 1 1 23.28
0 0 1 0 1 1 0 0 23.43
0 0 1 0 1 1 0 1 23.57
0 0 1 0 1 1 1 0 23.71
0 0 1 0 1 1 1 1 23.86
Automation Interface Switch Setting Chart - Division Factors 16 - 24
0 = DOWN = OFF, 1 = UP = ON
0 = DOWN = OFF, 1 = UP = ON
APPENDIX 8: INTERFACE PCB SWITCH SETTINGS
(Division Factors 16-24)
