PARTS LISTS 6-2 Manual 0-2727
6.03 System Replacement
Includes: CE Power Supply with Input Power Cable, EMI Filter Assembly, Work Cable & Clamp, Coolant, Torch &
Leads (as ordered), Torch Spare Parts Kit, and Operating Manual.
Qty Description Catalog #
CE PAK Master 150XL 380-415V Units:
With PCH 70° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1870-3
1 50 ft (15.2 m) Lead Length 1-1871-3
With PCH 90° Hand Torch
1 25 ft (7.6 m) Lead Length 1-1890-3
1 50 ft (15.2 m) Lead Length 1-1891-3
With PCM Machine Torch (Unshielded Leads & Remote Pendant)
1 25 ft (7.6 m) Lead Length 1-1880-3
1 50 ft (15.2 m) Lead Length 1-1881-3
With PCM Machine Torch (Shielded Leads & CNC Cable)
1 25 ft (7.6 m) Lead Length 1-1882-3
1 50 ft (15.2 m) Lead Length 1-1883-3
6.04 Power Supply Replacement
Includes: CE Power Supply with Input Power Cable, EMI Filter Assembly, Work Cable & Clamp, Coolant, and
Operating Manual.
Qty Description Catalog #
1 CE PAK Master 150XL Power Supply, 380-415V 3-1800-3
6.05 Basic Replacement Parts
Qty Description Catalog #
1 Fuse, 5 Amp, 600V, Delay 10-2274
1 In-Line Coolant Filter 8-3460
1 Coolant Filter 8-4276
1 Torch Coolant - 1 gal (3.78 liters)
Standard 25/75 Mix for Ambient Temperatures to +10°F (-12°C) 7-2850
Super 50/50 Mix for Ambient Temperatures to -34°F (-36°C) 7-2959
1 Deionizer Bag 8-3312
1 Two Stage Air Line Filter Kit 7-7502
Replacement Elements
1 First Stage 9-1021
1 Second Stage 9-1022
1 CE Shielded Primary Input Power Cable 9-7890
