13 of 32 © 2007 D 543 - 08/07
Item Field Range Access Description
– –:– – to 11:50 PM
or
– –:– – to 23:50
USER
INST
ADV
ALL DAYS OF THE WEEK SECTION I
Select the times for the scheduled events.
Note: This item is only available when the Schedule
Type is set to 24 hr.
Wake Default = 6:00 AM
UnOccupied Default = 8:00 AM
Occupied Default = 6:00 PM
Sleep Default = 10:00 PM
– –:– – to 11:50 PM or
– –:– – to 23:50
USEr
InST
Adv
MONDAY THROUGH FRIDAY SECTION I
Select the time for the scheduled events.
Note: This item is only available when the Heat or
Cool Schedule is set to Zone, to a Schedule Master
and Schedule Type is set to 5-2 or 5-11.
Wake Default = 6:00 AM
UnOccupied Default = 8:00AM
Occupied Default = 6:00 PM
Sleep Default = 10:00 PM
– –:– – to 11:50 PM
or
– –:– – to 23:50
USER
INST
ADV
SATURDAY AND SUNDAY SECTION I
Select the times for the scheduled events.
Note: This item is only available when the Schedule
Type is set to 5-2.
Wake Default = 6:00 AM
UnOccupied Default = 8:00 AM
Occupied Default = 6:00 PM
Sleep Default = 10:00 PM
– –:– – to 11:50 PM
or
– –:– – to 23:50
USER
INST
ADV
SATURDAY SECTION I
Select the times for the scheduled events.
Note: This item is only available when the Schedule
Type is set to 5-11 or 7dAY.
Wake Default = 6:00 AM
UnOccupied Default = 8:00 AM
Occupied Default = 6:00 PM
Sleep Default = 10:00 PM
Schedule Menu (2 of 4)
SC
HEDULE MENU
Continued on next page.
