tekmar 543 Thermostat Installation - Manual (Page 10)

© 2007 D 543 - 08/07 10 of 32
Item Field Range Access Description
SUNDAY, MONDAY,
TUESDAY,
WEDNESDAY,
THURSDAY, FRIDAY,
SATURDAY
Default = MONDAY
USER
INST
ADV
CURRENT TIME AND DAY SECTION H
Displays the current time and day of the week. The
time and date flash if the time is not set.
12:00 to :59
Default = :12:00 AM
USER
INST
ADV
CLOCK MINUTES SECTION H
Set the minutes.
12:00 AM to
11:59 PM or
00:00 to 23:59
Default = 12:00 AM
USER
INST
ADV
CLOCK HOURS SECTION H
Set the hours.
SUNDAY ...
WEDNESDAY ...
SATURDAY
Default = SUNDAY
USER
INST
ADV
DAY OF THE WEEK SECTION H
Set the day of the week.
12 hr to 24 hr
Default = 12
ADV
MODE SECTION H
Select whether time should be displayed using a 12
or a 24 hour clock.
The Time menu items set the time clock, day and date.
Time Menu (1 of 1)
TIME MENU
After the last item, the control returns to the first item in the menu.
