2 E-flite RV-9 450 Assembly Manual
Using the Manual
This manual is divided into sections to help make
assembly easier to understand, and to provide breaks
between each major section. In addition, check boxes
have been placed next to each step to keep track
of its completion. Steps with a single circle () are
performed once, while steps with two circles ( )
indicate that the step will require repeating, such as for
a right or left wing panel, two servos, etc.
Remember to take your time and follow the directions.
Product Registration
Register your product online at:
www.e-fliterc.com/register/
Contents of Kit/Parts Layout
EFL2776 Fuselage
EFL2777 Hatch
EFL2778 Wing Set (Left and Right)
EFL2779 Tail Set
EFL2780 Cowl
EFL2781 Canopy
EFL2782 Spinner
EFL2783 Landing Gear (Left and Right)
EFL2784 Wheels and Axles
EFL2785 Wheel Pants (Left and Right)
EFL2786 Hardware Set
EFL2787 Pushrod Set
Introduction
Thank you for purchasing the E-flite ® RV-9 450. The
sporty lines and spirited performance of the Van’s Aircraft
RV-9 has made it one of general aviation’s most popular
homebuilt aircraft. E-flite has perfectly captured the spirit
of this plane with this outstanding ARF that boasts true-to-
scale lines and, like its inspiration, is an absolute joy to
fly. To keep the scale lines unspoiled, E-flite has designed
the RV-9 with internal servo mounts that are concealed
from view. A classy red, yellow and blue UltraCote ® trim
scheme, cockpit details and factory painted fiberlass cowl
further enhance the realism. You even have the option of
adding functioning flaps for exciting short field takeoffs
and landings.
In the air, the RV-9 450 offers a nice balance between
maneuverability and stability that will please both
intermediate and experienced pilots.
The RV-9 450 ARF is another addition to E-flite’s
outstanding line of electric RC aircraft and accessories.
E-flite uses top-quality engineering and materials in
everything they make, so you always get the maximum
level of value and fun. And E-flite backs all of its products
with the best customer service and support in the hobby so
your electric flight experience is always a positive one.
IMPRESSIVE SCALE DEtAILS
Along with the true-to-scale outline of the wings and
fuselage, the RV-9 450 includes other scale touches such
as a detailed instrument panel, molded seatbacks and
room for two pilot figures (sold separately).
OPtIOnAL FLAPS
For the ultimate in realism, you can add the optional flaps
and enjoy short field takeoff and landing performance.
They’re already cut and hinged for you. Just add the servo.
Important Warranty Information
Please read our Warranty and Liability Limitations section
on Page 32 before building this product. If you as the
Purchaser or user are not prepared to accept the liability
associated with the use of this Product, you are advised
to return this Product immediately in new and unused
condition to the place of purchase.
table of Contents
Introduction ........................................................... 2
Important Warranty Information .............................. 2
Using the Manual ................................................... 2
Product Registration................................................ 2
Contents of Kit/Parts Layout .................................... 2
Recommended Radio Equipment ............................. 3
Recommended Standard Setup ................................ 3
Recommended High Power Setup ............................ 3
Optional Accessories .............................................. 3
Note on Lithium Polymer Batteries ........................... 3
Required Tools and Adhesives ................................. 3
Landing Gear Installation ........................................ 4
Tail Installation ....................................................... 4
Main Radio Installation ........................................... 7
Rudder and Elevator Linkage Installation .................. 9
Aileron Servo and Linkage Installation ................... 11
Joining the Wing Panels ....................................... 16
Fixed Flap Linkage Installation .............................. 18
Operational Flap Linkage Installation ..................... 20
Motor Installation ................................................. 23
Cowling Installation .............................................. 25
Wheel and Wheel Pant Installation ........................ 26
Canopy Detail Installation ..................................... 28
Wing Installation .................................................. 29
Control Throws..................................................... 30
Center of Gravity ................................................. 30
Preflight ............................................................... 31
Range Test Your Radio .......................................... 31
Flying Your RV-9 .................................................. 31
Safety Do’s and Don’ts for Pilots ............................ 32
Age Requirements ................................................ 32
Safety, Precautions and Warnings ......................... 32
Warranty Information ........................................... 32
Instructions for Disposal of WEEE by
Users in the European Union ............................ 34
2008 Official Academy of
Model Aeronautics Safety Code ....................... 34
