22 E-flite Divo 3D Profile Assembly Manual
 4. Slide the pushrod through the holes in the connectors.
With the bottom aileron in neutral, secure the pushrods to
the connectors using two 2mm x 4mm machine screws.
 5. Attach the bend of each of the 7.9-inch (200mm)
pushrods to the control horns on the bottom wing.
 6. With both the top and bottom ailerons centered,
secure the pushrods to the connectors at the top ailerons
using 2mm x 4mm machine screws.
 7. Attach a long servo arm to the elevator and rudder
servos after centering the servo using the radio. Install a
micro control connector to the end of the servo arms.
