14 E-flite Divo 3D Profile Assembly Manual
Carbon Rod Installation
Required Parts
Assembled airframe
Carbon rod, 5.4-inch (137mm) (4)
Carbon rod, 5.1-inch (130mm) (2)
Carbon rod, 19.4-inch (492mm)
Carbon rod, 12.8-inch (325mm) (4)
Required Tools and Adhesives
Foam-safe CA Foam-safe CA activator
Straight edge
Note: You must take extra care in these next few steps
to maintain the alignment of your airframe and to not
build in any unwanted twists in the airframe. Make sure
to keep everything aligned and the wings straight with
the fuselage. Also make sure not to induce any twist
in the wings, which could adversely affect the flight
characteristics of your aircraft.
 1. Slide the 19.4-inch (492mm) carbon rod through the
cabane struts and fuselage. Center the carbon rod and
check that both struts are not bent using a straight edge.
Use foam-safe CA to glue the carbon rod to both struts
and fuselage.
