Banner Safety Mat Monitoring Modules User Manual
Sm-xa-5a safety mat monitoring modules, Overview

SM-GA-5A (12-24V dc / 115V ac operation) and SM-HA-5A (12-24V dc / 230V ac operation)
The user is responsible for satisfying all local, state, and national laws, rules,
codes, and regulations relating to the use of this product and its application. Banner
Engineering Corp. has made every effort to provide complete application, installa-
tion, operation, and maintenance instructions. Please direct any questions regard-
ing the use or installation of this product to the factory applications department at
.
The user is responsible for making sure that all machine operators, maintenance
personnel, electricians, and supervisors are thoroughly familiar with and understand
all instructions regarding the installation, maintenance, and use of this product, and
with the machinery it controls. The user and any personnel involved with the instal-
lation and use of this product must be thoroughly familiar with all applicable stand-
ards, some of which are listed within the specifications. Banner Engineering Corp.
makes no claim regarding a specific recommendation of any organization, the accu-
racy or effectiveness of any information provided, or the appropriateness of the pro-
vided information for a specific application.
Model
Supply Voltage
Outputs
Output Rating
SM-GA-5A
12-24V dc or 115V ac
4 Normally Open Safety
1 Normally Closed Aux.
2 Solid-State Aux.
N.O. Safety Outputs: 6 A
N. C. Aux. Outputs: 5 A
SS Aux Outputs: 100 mA
SM-HA-5A
12-24V dc or 230V ac
122364_web.
WARNING: Not a Stand-Alone Safeguarding Device
This Banner product is not a stand-alone point-of-operation guarding device, as defined by OSHA regulations. It is necessa-
ry to install point-of-operation guarding devices, such as safety light screens and/or hard guards, to protect personnel from hazardous
machinery. Failure to install point-of-operation guards on hazardous machinery can result in a dangerous condition which
could lead to serious injury or death.
Overview
Safety Mat Monitor Modules SM-GA-5A and SM-HA-5A (the "Safety Module") are used to verify the proper operation of 4-wire presence-sensing switching mats (sensors).
SM-xA-5A Safety Mat Monitoring Modules
P/N 122364 rev. C
8/22/2012
