Category

Specification

Max. switching current: 100 mA at 12-24V dc
Both outputs are protected against short circuits.
Output at Y32 monitors state of outputs – conducts (output high) when both K1 and K2 are energized.
Output at Y35 conducts (output high) when in normal operation (no lockout).

Output Response Time 35 ms max. (25 ms typical)

Input Requirements

Safety mat normally open contact must be capable of switching 20 to 100 mA @ 12 to 30V dc; and must be
closed > 25 ms for a valid stop command.

V ac or 24V dc Supply: Max. lead resistance 250 ohms; max. contact resistance: 150 ohms.

12V dc Supply: Max. lead resistance 25 ohms; max. contact resistance: 10 ohms.

Reset switch: must have one normally open contact capable of switching 20 to 50 mA @ 12 to 30V dc.

OFF-State Recovery
Time

350 ms maximum

Indicators

3 green LED indicators: Power ON, Channel 1 (high side), Channel 2 (low side)

1 red LED indicator: indicates a fault condition (see Troubleshooting)

Construction

Polycarbonate housing. Rated NEMA 1, IEC IP20

Mounting

Mounts to standard 35 mm DIN rail track. Safety Module must be installed inside an enclosure rated NEMA 3
(IEC IP54), or better.

Vibration Resistance

10 to 60 Hz @ 0.35 mm peak displacement per UL 991

60 to 150 Hz @ 5 g max.

Operating Conditions

Temperature: 0° to +50°C (+32° to 122°F), (surrounding air)

Max. Relative Humidity: 90% @ +50°C (non-condensing)

Design Standards

Cat. 4 PL e per EN ISO 13849-1; SIL 3 per IEC 61508 and IEC 62061

Certifications

SM-xA-5A Safety Mat Monitoring Modules

P/N 122364_Web
rev. C
