Rope Pull Emergency Stop Switches –
RP-LS42F-75L.. Series
8
P/N 67709 rev. A
Banner Engineering Corp. • Minneapolis, MN U.S.A.
www.bannerengineering.com • Tel: 763.544.3164
Contact Rating
10A @ 24V ac, 10A @ 110V ac, 6A @ 230V ac
6A @ 24V dc
2.5 kV max. transient tolerance
NEMA A300 P300
European Rating
Utilization categories: AC15 and DC13
Ui = 500V ac
Ith = 10A
40-60 Hz
U
e
V
I
e
/AC-15
A
I
e
/DC-13
A
24
10
6
110
10
1
230
6
0.4
Contact Material
Silver-nickel alloy
Maximum Switching Speed
50 operations per minute
Recommended Rope Size
3 mm diameter steel rope (See Accessories, p. 10)
Maximum Rope Pull Length
75 m (245')
Short Circuit Protection
10 amp Slow Blow, 15 amp Fast Blow. Recommended external fusing or overload protection.
Mechanical Life
1 million operations
Wire Connections
Screw terminals with pressure plates accept the following wire sizes –
Stranded and solid: 20 AWG (0.5 mm
2
) to 16 AWG (1.5 mm
2
) for one wire
Stranded: 20 AWG (0.5 mm
2
) to 18 AWG (1.0 mm
2
) for two wires
Cable Entry
M20 x 1.5 threaded entrance
Adapter supplied to convert M20 x 1.5 to ½" - 14 NPT threaded entrance
Construction
High-impact thermoplastic housing; zinc die-cast actuator
Environmental Rating
NEMA 4, IEC IP67
Operating Conditions
Temperature:
-25° to +70° C (-22° to +176° F)
Weight
RP-LS42F-75L: 0.48 Kg (1.05 lbs.)
RP-LS42F-75LE: 0.65 Kg (1.43 lbs.)
RP-LS42F-75LF: 0.65 Kg (1.43 lbs.)
Certifications
Specifications
