• Repair any loose or damaged hardware, worn/frayed rope (cable), missing red rope sheathing or flags/markers (if
used)
• Remove or clean off any contamination and eliminate its cause
Repairs
Contact Banner Engineering for troubleshooting of this device. Do not attempt any repairs to this Banner device; it
contains no field-replaceable components. If the device or a device component is determined to be defective by a
Banner Applications Engineer, they will advise you of Banner's RMA (Return Merchandise Authorization) procedure.
Important: If instructed to return the device, pack it with care. Damage that occurs in return shipping
is not covered by warranty.
Specifications
Contact Rating
10 A at 24 V ac
10 A at 110 V ac
6 A at 230 V ac
6 A at 24V dc
2.5 kV max. transient tolerance
NEMA A300 P300
European Rating
Utilization categories: AC15 and DC13
Switches with 1 and 2 contact pairs: Ui = 500V ac; Ith
= 10A
40-60 Hz
Ue (A) Ie/AC-15 (A) Ie/DC-13 (A)
24 10 6
110 10 1
230 6 0.4
Contact Material
Silver-nickel allow
Maximum Switching Speed
50 operations per minute
Recommended Rope Size
2 mm diameter steel rope
Maximum Rope Pull Length
6 m (20 ft)
Short Circuit Protection
10 amp Slow Blow, 15 amp Fast Blow. Recommended
external fusing or overload protection.
Mechanical Life
1 million operations
Wire Connections
Screw terminals with pressure plates accept the
following wire sizes –
Stranded and solid: 20 AWG (0.5 mm
2 ) to 16 AWG
(1.5 mm 2 ) for one wire
Stranded: 20 AWG (0.5 mm 2 ) to 18 AWG (1.0 mm 2 )
for two wires
Cable Entry
M20 x 1.5 threaded entrance. Adapter supplied to
convert M20 x 1.5 to ½"-14 NPT threaded entrance
Construction
Aluminum alloy die-cast
Environmental Rating
IEC IP65
Operating Conditions
Temperature: –30 to 80 °C (–22 to 176 °F)
Weight
RP-LM40D-6: 0.22 Kg (0.49 lbs)
RP-LM40D-6L: 0.26 Kg (0.57 lbs)
Certifications
RP-LM40 Series Rope Pull Switches
