Models SC-IM9.. – Safety Controller Interface Modules
P/N 131845
WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp.
will repair or replace, free of charge, any product of its manufacture found to be defective at the time it is returned to the factory
during the warranty period. This warranty does not cover damage or liability for the improper application of Banner products.
This warranty is in lieu of any other warranty either expressed or implied. WARRANTY: Banner Engineering Corp. warrants its products to be free from defects for one year. Banner Engineering Corp.
will repair or replace, free of charge, any product of its manufacture found to be defective at the time it is returned to the factory
during the warranty period. This warranty does not cover damage or liability for the improper application of Banner products.
This warranty is in lieu of any other warranty either expressed or implied.
Accessories
Model Description Contacts Positively Guided
11-BGX10-40
Non-Safety Auxiliary Contacts:
Adds normally open contacts to the primary contactor(s).
3 N.O. No (Aux. only)
Model Description Voltage
11-BGX77-048
Suppressor for Mechanically Linked Contactors:
Extends the life of the actuating device—such as a light screen or control module—that
uses a mechanically linked contactor. (Two required for each pair of relays.)
48V dc (max.)
Figure 3. Dimensions
47 mm (1.9")
(SC-IM9A)
94 mm (3.7")
(SC-IM9B)
141 mm (5.6")
(SC-IM9C)
172 mm (6.8")
88 mm (3.5")
66 mm (2.6")
113 mm (4.5")
29 mm (1.1")
CL
