Important: If instructed to return the device, pack it with care. Damage that occurs in return shipping
is not covered by warranty.
Specifications
Contact Rating
10 A at 24 V ac
10 A at 110 V ac
6 A at 230 V ac
6 A at 24V dc
2.5 kV max. transient tolerance
NEMA A300 P300
European Rating
Utilization categories: AC15 and DC13
Ui = 500 V ac; Ith = 10 A
40-60 Hz
Ue (V)
Ie/AC-15 (A)
Ie/DC-13 (A)
24
10
6
110
10
1
230
6
0.4
Contact Material
Silver-nickel allow
Maximum Switching Speed
50 operations per minute
Recommended Rope Size
3 mm diameter steel rope
Maximum Rope Pull Length
RP-QM72D-6L: 6 m (20 ft)
RP-QM72D-12L: 12 m (40 ft)
RP-QMT72D-20L: 20 m (66 ft)
RP-QMT72E-12L: 12 m (40 ft)
RP-QMT72F-12L: 12 m (40 ft)
Short Circuit Protection
10 amp Slow Blow, 15 amp Fast Blow. Recommended
external fusing or overload protection.
Mechanical Life
1 million operations
Wire Connections
Screw terminals with pressure plates accept the
following wire sizes –
Stranded and solid: 20 AWG (0.5 mm
2
) to 16 AWG
(1.5 mm
2
) for one wire
Stranded: 20 AWG (0.5 mm
2
) to 18 AWG (1.0 mm
2
)
for two wires
Cable Entry
M20 x 1.5 threaded entrance. Adapter supplied to
convert M20 x 1.5 to ½"-14 NPST threaded entrance
Construction
Aluminum alloy die-cast
Environmental Rating
IEC IP65
Operating Conditions
Temperature: –30 to 80 °C (–22 to 176 °F)
Weight
RP-QM72D-6L: 0.49 Kg (1.08 lbs)
RP-QM72D-12L: 0.52 Kg (1.15 lbs)
RP-QMT72D-20L: 0.64 Kg (1.41 lbs)
RP-QMT72E-12L: 0.64 Kg (1.41 lbs)
RP-QMT72F-12L: 0.64 Kg (1.41 lbs)
Certifications
Rope Pull Switches
P/N 62084 Rev. C
