Application Notes: When rotating the actuator head, the actuator
MUST BE FULLY ENGAGED.
When using a model with solenoid locking, the lock mechanism will
disengage upon solenoid power failure. Certifications:
Dimensions
Switch Dimensions Actuator Dimensions
ø 5.2 mm
(0.20")
34 mm
(1.3")
100.0 mm
(3.94")
41.3 mm
(1.63") 5.2 mm
(0.20") (x3)
30.0 mm
(1.18")
8.0 mm
(0.31")
(x2)
2.0 mm
(0.08")
6.5 mm
(0.26")
60.0 mm
(2.36")
36.8 mm
(1.45")
3.0 mm
(0.12")
90.0 mm
(3.54")
45.0 mm
(1.77")
20.0 mm
(0.79")
17.5 mm
(0.69")
9.8 mm
(0.39")
50.0 mm
(1.97")
≥ 80 mm
(3.1")
20.0 mm
(0.79")
30.0 mm
(1.18")
Access to
Manual Release
(SI-QM100..MSG
Series only)
M20 x 1.5
1/2"-14 NPT
Adapter is Supplied
ø 4.8 mm (2)
22.0 mm
(0.87")
2.5 mm
(0.10")
20.0 mm
(0.79")
7.5 mm
(0.30")
15 mm
(0.59")
80.0 mm
(3.13")
ø 4.8 mm
(2 Holes)
Accessories
Cable Glands
Model Size For Cable Diameter Dimensions Used With
SI-QM-CGM20 M20 × 1.5 Metal
5.0 to 12.0 mm (0.20
to 0.47 inches)
M20 x 1.5
24.0 mm
(0.94")
35.5 mm
(1.40")
SI-LM40 Safety Interlock
Switches
SI-QM100 Safety Interlock
Switches
RP-RM83 Rope Pull Switches
RP-LM40 Rope Pull Switches
RP-QM72/QMT72 Rope Pull
Switches
RP-QM90 Rope Pull Switches
Replacement Parts
Model Size Thread Conversion Dimensions Used With
SI-QM-M20 ½"-14 NPT Metal
M20 x 1.5 to ½"-14
NPT
23.0 mm
(0.91")
M20 x 1.5
24.0 mm
(0.94")
1/2"-14 NPT
Internal Thread
O-ring
SI-LM40 Safety Interlock
Switches
SI-QM100 Safety Interlock
Switches
RP-RM83 Rope Pull Switches
RP-LM40 Rope Pull Switches
RP-QM72/QMT72 Rope Pull
Machine Safety Switches
P/N 049374 Rev. F www.bannerengineering.com - tel: 763-544-3164 7
