3 Operation
861 Advanced Compact IC / Instructions for Use 8.861.1033
54
3.2.2 Connect a system
The selected system must be linked to the workplace for controlling the
instrument and starting determination processes. Systems are linked by
selecting SYSTEM / Control / Connect to workplace (see also Software In-
structions for Use «IC Net 2.3», Section 4.3.1).
3.2.3 Instrument icon
System disconnected System connected
Injection valve in
"INJECT" position
System connected
Injection valve in "FILL"
position
The instrument icon for the 861 Advanced Compact IC is one of the
three elements in the System window. If the system is linked (see Sec-
tion 3.2.2), the icon is provided with two buttons for manual operation of
the injection valve:
Switch over the injection valve to position "INJECT".
Switch over the injection valve to position "FILL".
When you click with the right mouse button on the instrument icon, you
will see the following menu:
