— 29

 PSI PER FEET 0.000205

REY 6120.09

PSF PER FEET 0.029469

inHG PER FEET 0.000417

HEAD PER FEET 0.000472

BAR PER FEET 0.000014

KPA PER FEET 0.001411

PSI PER FEET 0.000205
Using values above, add the Run (Length) to calculate the
Pressure Loss over the length of the pipe.
KEYSTROKES DISPLAY

   RUN 50 FEET 0 INCH
Calculate Pressure Loss

 PSI 0.010232

REY 6120.09

PSF 1.47346

inHG 0.020833

HEAD 0.023603

BAR 0.000705

KPA 0.07055

PSI 0.010232
You can also change the Flow Rate and recalculate the
Pressure Loss.
KEYSTROKES DISPLAY

   GPM 40.
 
PSI 0.575408

REY 61200.9

PSF 82.85877

inHG 1.171543

HEAD 1.32727

BAR 0.039673

KPA 3.9673

PSI 0.575408
