— 25

(setback) STBK 6-3/8 INCH

BEND 45.00 º

OFST 5 INCH

ROLL 4 INCH
Calculating Drop
If a pipe Run requires 1/8" drop per foot for drainage, how
much total drop is required for a 25' Run?
KEYSTROKES DISPLAY

 0.
1. Enter the Slope (Drop):

   SLP 0 1/8 INCH
2. Calculate the total drop (Offset):

    OFST 0 FEET 3 - 1/8 INCH
Find the slope of a pipe Run if it drops 6 inches over 50 feet.
What is its Angle and Percent Grade?
KEYSTROKES DISPLAY

 0.
1. Enter the Run:

   RUN 50 FEET 0 INCH
2. Enter the Offset:

  OFST 6 INCH
3. Calculate the Percent Grade, Slope and Angle:

 % GRD 1.

GRD 0.01

SLP 0 1/8 INCH

/Ø 0.57º
