You can also directly enter a Pipe Type, e.g., Schedule 80, by
entering a number corresponding to the pipe type.
KEYSTROKES DISPLAY

 0.

MATL PLASTIC

   Type 80 PLASTIC
Pipe Size Key
When you have chosen a Pipe Material and Type and then
enter Pipe Size, the pipe data will be displayed.
For this example we are using 3" Steel, Schedule 80 pipe.
KEYSTROKES DISPLAY
 
0.
1. Choose the Pipe Material:

MATL STEEL
2. Enter the Pipe Type:

   Type 80 STEEL
3. Enter the Pipe Size:

 3 INCH
4. Toggle through the Pipe data:

80 - SIZE 3 INCH

(Outside Diameter) OD SIZE 3.5 INCH

(Internal Diameter) ID SIZE 2.9 INCH

(Wall Thickness) THK SIZE 0.3 INCH

(Material) MATL SIZE STEEL

(Weight per Foot) PIPE SIZE 10.2528 LB Per FEET

(Filled Weight/Foot) FILL SIZE 13.11634 LB Per FEET

(Internal Area) AREA SIZE 6.605199 SQ INCH
