Notice to PC User
A small filter core and cable tie are enclosed in the vinyl bag with your
MFC. PLEASE SAVE THESE PARTS. You will need them in the future
if you connect MFC with a Personal Computer. And for optimal
performance, use the Double Shielded Parallel Interface Cable with
enclosed Filter core and Cable tie.
When you use a Personal Computer with your MFC, please attach the
enclosed Filter core to Double Shielded Parallel I/F Cable.
How to Attach the Filter Core to the Double Shielded
Parallel I/F Cable:
1
Attach the Cable tie 50mm or less from Parallel Interface connector.
50mm
Double shielded
Parallel I/F cable
Cable tie
Cable tie
to MFC
Parallel Interface
connector
Double shielded
Parallel I/f cable
2
Attach the Filter core, pressing until you hear a click, between the
Parallel Interface connector and the Cable tie.
Double shielded
Parallel I/F cable
Cable Tie
Filter Core
Filter Core
to MFC
