Brandmotion 9002-8601 User Manual
Installation instructions

INSTALLATION INSTRUCTIONS
8601 Instructions 7-20-12.doc
Page 1 of 4
OEM Recessed Lip Camera with Harness
(Kit part number 9002-8601)
Please read thoroughly before starting installation
and check that kit contents are complete.
Items Included in the Kit:
Tools & Supplies Needed:
Bubble bag containing:
Camera with Mount (in zip lock bag)
Camera Harness
Video Display Harness
Chassis Harness
Zip lock bag containing:
12 Zip Ties
2 Rubber Nuts
2 Bolts
2 sets of T-taps
Zip lock bag containing:
These Instructions
Template
Phillips Screwdriver
5/16” & 1/2” Drill Bits
Power Drill
Roto Tool
File
Multi-meter or computer safe test light
Wire Ties or Electrical Tape
Wire Crimper
Ground Eyelet
(Recommended)
Soldering Iron
Solder
(Recommended)
or T-Taps
Plastic trim removal tool
Rubber Grommet or Silicone Caulk
(Recommended)
Vehicle service manual
(If needed)
Additional Parts That May Be Needed (see Application Guide. Parts sold separately):
5000-VWAB Volkswagen mirror mount adapter
5000-CAMLOCK Honda/ Subaru mirror mount adapter
Safety Precautions:
•
Work in well ventilated area that is clear of obstructions.
•
Secure vehicle with tire chucks in both front and rear of tires.
•
Turn vehicle accessories OFF and ensure ignition key is in OFF position.
•
Wear safety goggles and snug fitting clothes.
•
Use tools only for their intended purpose and which are in good repair.
•
Only perform this task if confidence, skill, and physical ability permit.
NOTE: We strive to provide accurate and up-to-date installation instructions. For the latest full color
instructions, as well as an installation video, please visit www.brandmotion.com
