Step 20: Connect supplied Mirror Harness to Chassis
Harness. Cut and isolate the three red, green, and black
wires at the 6-pin connector using electrical tape.
Install Mirror Harness
Follow Steps 21 through 28 ONLY for 2013 to
current vehicles with factory auto dimming
mirrors.
For 2007 to 2012 vehicles equipped with non-
powered mirrors, proceed to Step 29.
Step 21: Begin running 16-pin mirror connector end of
Mirror Harness to mirror by first removing IP access
panel.
Step 22: Remove passenger side sun visor using a T15
Torx bit.
Step 23: Use a Phillips screwdriver to remove Phillips
fastener on upper-A pillar and remove pillar.
Step 24: Remove lower A-pillar cover (no tools
required).
Step 25: Pull down right side of header panel.
Step 26: Run supplied Mirror Harness to Mirror location.
