10
Remote control of the Z_CAL :
The instrument functions are controlled externally by an ASCII code corresponding to the 3
first letters of the function. Spaces are removed. The message may be in upper or lower case.
The question mark ? implies an instrument response.
? or PRI (PRInt) requests displayed value
CLE (CLEar) reinitialises the maximum / minimum memories
EXT0 external contact = data transmission
EXT1 external contact = display preset
EXT2 external contact = normal mode
↔
diameter mode
EXT3 external contact = reference mode 1
↔
reference mode 2
EXT? asks for current function of external contact
(EXTernal contact)
EXTB...
same as above, but for Print key functions
ID? (Identification) Z_CAL replies : SYLVAC Z_CAL
IN (Inch) display unit
MM (MilliMeter) display unit
KEY0 (KEYboard) keyboard locked
KEY1 keyboard unlocked
AXI (AXIs) centerline mode
DIA (DIAmeter) diameter mode
DEL (DELta) maximum - minimum difference mode
NOR (NORmal) normal mode
MAX (MAXimum) maximum mode
MIN (MINimum) minimum mode
MOD? (MODe) interrogation of the measuring mode : NOR,DIA,AXI,MIN,MAX,DEL
POS + number the instrument positions itself to the value transmitted. If an obstacle
inhibits movement, positionning is given up.
PRE (PREset) displays the preset value
PRE + number memorises a new preset value
PRE? interrogates the memorised preset value
REF1 reference 1
REF2 reference 2
RES2 (RESolution) 0.001 mm - 0.00005 in resolution
RES3 0.01 mm - 0.0005 in resolution
SET? (SETting) interrogation of general parameters :
MM/IN RES2/3 REF1/2 KEY0/1 B0/1. B0 = battery recharging.
UNI? (UNIt) measuring unit : MM or IN
UNI1 mm/inch conversion unlocked
UNI0 mm/inch conversion locked
VER? (VERsion) instrument program version and date
