3-44 SB3000 Drive Configuration and Programming
Parallel Power Module C Status Register (Continued) 221/1221
Phase W-Upper IOC C Bit 2
The Phase W-Upper C status bit is set if an
IOC or DSAT fault occurs in Power Module
C’s phase W, upper power device. Hex Value: 0004H
Sug. Var. Name: W_UPC@
Access: Read only
UDC Error Code: N/A
LED: N/A
Phase U-Lower IOC C Bit 3
The Phase U-Lower IOC CC status bit is set
if an IOC or DSAT fault occurs in Power
Module C’s phase U, lower power device. Hex Value: 0008H
Sug. Var. Name: U_LOC@
Access: Read only
UDC Error Code: N/A
LED: N/A
Phase V-Lower IOC C Bit 4
The Phase V-Lower C status bit is set if an
IOC or DSAT fault occurs in Power Module
C’s phase V, lower power device. Hex Value: 0010H
Sug. Var. Name: V_LOC@
Access: Read only
UDC Error Code: N/A
LED: N/A
Phase W-Lower IOC C Bit 5
The Phase W-Lower C status bit is set if an
IOC or DSAT fault occurs in Power Module
C’s phase W, lower power device. Hex Value: 0020H
Sug. Var. Name: W_LOC@
Access: Read only
UDC Error Code: N/A
LED: N/A
Intelligent Power Module C Bit 6
The Intelligent Power Module C bit is set to
indicate that a DSAT (shoot-through) fault
has occurred in Power Module C. Hex Value: 0040H
Sug. Var. Name: IPUC@
Access: Read only
UDC Error Code: N/A
LED: N/A
Bits 0 - 5 of this register should be checked to identify the device in which the fault
occurred.
